Windows with lower transom
ERGONOMICS AND COMFORT OF USE
- Richly equipped double sash window.
- The upper sash is opened like a pivot window with its axis of rotation situated above the centre of the window, so even a tall person can easily walk up to the window edge.
- Duet proSky window eliminates the need for traditional vertical combinations, thus offering a greater illumination area.
INTUITIVE OPERATION AND FUNCTIONALITY
- Easy operation by means of the handle positioned in the base of the sash and featuring two-step micro-opening.
- The hinge enables the sash to be rotated and left open. The sash when opened in position from 0° to 45° is supported by innovative supporting mechanism.
- The sash can be rotated through 160° and locked allowing safe and easy cleaning of the outer pane.
ENERGY-EFFICIENT DESIGN
- Manufactured in thermoPro technology to result in higher energy-efficiency performance, greater durability, excellent tightness and facilitated installation process.
- Quadruple sealing system provides additional tightness in extreme weather conditions and reduces micro vibrations of the cladding profiles during heavy rain.
- The internal glass is laminated and features P2A anti-burglary class.
- Sound-insulating glass effectively reduces noise penetration.
LONG-LASTING PROTECTION
- Made of vacuum impregnated pinewood.
INCREASED SAFETY
- Toughened external glass with lifetime hail resistance warranty.
- Increased operational safety and burglary resistance – topSafe system.
FUNCTIONAL ACCESSORIES
- Wide range of additional accessories.
INSTALLATION RANGE
- 25-65˚
CLADDING COLOUR
- Anthracite RAL 7016 - standard
- Grey-brown RAL 7022
- Black RAL 9005
INTENDED USE
- Recommended for buildings where special emphasis is put on thermal energy savings.
- Suitable for installation in horizontal combinations.
-
FDP-X P50 APMX
-
high-quality pinewood, glued in layers and vacuum impregnated
-
coated twice with eco-friendly water based varnish in natural colour
FDP-X P50 APMX
- 1.1 W/m²K || 1.0 W/m²K with Thermo flashing trasmittanza termica Uw 0.55 W/m²K trasmittanza termica Ug (secondo EN 673) 40 dB isolamento acustico Rw Triple-glazed unit vetrocamera + verto esterno temperato + vetro esterno con pellicola autopulente + vetro interno laminato (sicuro) Without air inlet. With air inlet upon request. tipo di ventilazione twice verniciatura del legno + microapertura
-
